All aluminum system-EISEN

The partition wall system is made of all-aluminum structure, aluminum profile is made of 6063 alloy and T5 state extrusion. The vertical and horizontal support frame of the compartment has a high-precision aluminum profile keel with a wall thickness of 1.8mm, and the wall thickness of the partition external profile is 1.2MM- 2.2MM high-precision aluminum profiles, the surface is usually anodized or powder sprayed. The color, film thickness and film quality are in line with national standards GB 5237.1-2008 "Aluminum Alloy Building Profiles Part 1: Substrate", GB 5237.2-2008 "Aluminum Alloy Building Profiles Part II: Anodized or Powder Sprayed Profiles".

Glass module: 5mm or 6mm 铯K fireproof glass.

Finishing module: 12mm thickness of any panel or 0.8mm environmentally friendly galvanized steel lining 12mm gypsum board.

double-layered glass

Wall structure: all aluminum system
Wall appearance: wall thickness 100mm, upper and lower rail height 76mm, column width 20mm,
Glass assembly: Safety or fireproof glass with a thickness of 5 or 6 mm.
Panel assembly: 15mm thickness of any panel or 0.7mm environmentally friendly galvanized steel lining 15mm gypsum board.
Fire endurance: EI60min
Impact strength: 450Nm
Sound insulation load: 43dB-48dB

Suggestion: In order to achieve better sound insulation effect, it is best to arrange different thickness of glass on the front and back sides. The area of single glass is not more than 3m2. At the same time, it should consider adding unnecessary cost during transportation.
Double glass louver

Metal blinds selection
Width of venetian blinds: 16mm, 25mm, 50mm
Thickness of venetian blind: 0.21mm
The choice of the color of the louver: can be freely matched according to the color of the profile.
The use of louvers: external manual knob, electric flip dimming electric lift belt flip dimming.

Suggest:
1. In order to ensure better use of the manual knob and motor unit, the width of a single set of louvers does not exceed 1150mm.
2, the selection of high-quality venetian blinds, which can ensure good visual effects and aesthetics for a long time, and can avoid the trouble of having to disassemble the partition wall due to the replacement of poor venetian blinds.
Decorative panels

Wall structure: all aluminum system
Wall appearance: wall thickness 100mm, upper and lower rail height 76mm, column width 20mm.
Panel assembly: 12mm thickness of any panel or 0.8mm environmentally friendly galvanized steel lining 12mm gypsum board.
Fire endurance: EI60min
Impact strength: 450Nm
Sound insulation load: 39dB-45dB

Note: The width of the steel panel is between 300mm and -1150mm. The height is not limited. It only needs to be transported and loaded. The surface of the panel can be treated with solid color or wood grain color, and the color and texture are rich and varied.
